Senhaix N60 Network Radio 4G LTE PoC WiFi Bluetooth Android Smart Intercom GPS GSM Antenna Zello Wireless Communication
Product Features
1. OS-Android
2. Screen – 4.5 Touch LCD display
3. GPS Funtion(Logitute&Latitute Location)
4. WIFI
5. Bluetooth
6. Online Upgrade
7. Play Store
8. Phone Function
9. SOS Function
10. Zello APP
11. All Call, Group Call & Individual Call
Technical Specifications
General Specification
- Model No.SPTT-N60
- Dimension170x80x85mm
- Weight380g
- Screen Size4.5 inches Touch LCD
- Working VoltageDC 10-24V
- Working Temperature-30℃ to +75℃
- Platform ManagementREAL PTT
- Talk RangeUnlimited
- RF Parameter
- Frequency RangeGSM 850/1900MHz 900/1800MHz
- WCDMA 850/1900MHz 900/2100MHz
- Maximum Output PowerWCDMA 2100/1900/900/850MHz:
- Power class 3 (+24dBm +2.5/-1.5dBm)
- GSM/GPRS 850MHz/900MHz:
- Power class 4 (+33dBm +2.5/-0.5dBm)
- GSM/GPRS 1800MHz/1900MHz:
- Power class 1 (+30dBm +2.5/-0.5dBm)
- Receiving SensitivityWCDMA 2100: ≤-108dBm
- WCDMA1900: ≤-109dBm
- WCDMA900: ≤-109dBm
- WCDMA850: ≤-109dBm
- GSM850/900/1800/1900: ≤-107dBm
- GPS
- GPS Positioning, Support A-GPS function, 1.57542GHz;
- SensitivityCatch -144dBm, Track -159dBm
- Technical Sensitivity
- Data Speed RateGSM CS: UL 9.6kpbs/ DL 9.6kpbs
- GPRS: Multi-slot Class 10
- EDGE: Multi-slot Class 12
- WCDMA CS: UL 64kpbs/ DL 64kpbs
- WCDMA PS: UL 384kpbs/ DL 394kpbs
- ProtocolHSDPA/WCDMA/EDGE/GPRS/GSM
WIFI
- WIFIIEEE 802.11 b/g/n , 2.4G;
- Maximum RF power≤20dBm
- Receiving SensitivityIEEE 802.11 g: ≤-65dBm;
BT
- BT Support V4.0,V3.0,V2.1
- Maximum RF powerClass 1 ≤10dBm;
- Receiving SensitivityGFSK: ≤-95dBm,DQPSK: ≤-94dBm , DPSK: ≤-88dBm;
We are professional manufacturer of two way communications and PoC Mobile Radio.
